Technical Specification
• Main Motor: 5,5 Kw Krm Type Gear Motor 1 Piece
• Clawed Double Row Chain (16 B2 Steel)
• Glue Cylinder 1 Piece
• Paper Feeding Unit (0,55 Kw Servo Motor Drive)
• Paper Feeding Unit Magazine (Capacity: 2000)
• Plc System Control Unit (Omron / Siemens)
• Automatic Feeding Unit (Hourly Capacity According to Your Preference)
• Label Plaster System (Pneumatic Piston)
• Wagon System (Easy to Change Wagon 1 * 10/1 * 15/2 * 6)
• Automatic Adding (Program Channel Automatic Collection)
• Machine Chassis (Aluminum 6083 and Steel 1040)
• Drive Transmission (One Shaft Trig / Rac and Pinion Gear)
• Hourly Production Capacity Changes for 3500/4000 Products
• Wagon Production Will Be Designed and Produced According to Your Molds.
